BUMPER SINGLE AXLE STANDARD DUTY UTILITY 3500lb GVWR

Model #: BSSTDUT 3,500lb GVWR

Standard Features

■ COUPLER: 2" - ATWOOD W/COUPLER HOLE COVER PLATE■ TIRES: NEW ST205/75/R/15" RADIALS LOAD RANGE "C" 6-PLY■ FLOOR: PRESSURE TREATED/2"X8"PINE,DOUBLE SCREWED/PER/RUN
■ SAFETY CHAIN: 1/4" CHAIN W/SAFETY HOOKS■ WHEELS: 5 - HOLE POWDER COATED SILVER MODS / GM-5"-BP■ STICKERS: WARNING & SAFETY & REFLECTIVE KEARNEY LOGOS
■ JACK: 2K TOP WIND W/INTERCHANGEABLE PIN ON SAND FOOT * JACK IS SET BACK FOR TAILGATE OPENING CLEARANCE■ TONGUE: 5'X 12'& SMALLER - 3" X 2" X 3/16" ANGLE IRON * 5'X 14'& ALL 77"WIDES - 4" X 3" X 1/4" ANGLE IRON■ EXT PREPPING: 2 STAGE DEGREASING AND ACID PHOSPHATE WASH W/RUST-INHIBITOR TO ENSURE MAXIMUM PAINT ADHESION
■ PLUG: 4 - WAY MOLDED PLUG HARNESS / GROUNDED TO FRAME■ FRAME: 3" X 2" X 3/16" ANGLE IRON■ EXT. FINISH: PAINTED WITH A NEWLY INNOVATED, DURABLE HIGH GLOSS ACRYLIC POLYURETHANE FULL TWO-COMPONENT FINISH
■ LIGHTS: "LED" RUBBER MOUNTED RUNNING, STOP, TURN & CLEARANCE■ CROSSMEMBERS: 3" X 2" X 3/16" ANGLE IRON■ UNDERCOATING: COMPLETELY COATED W/A DURABLE PROTECTIVE FINISH
■ FENDERS: 9" X 32" ROLLED SMOOTH W/SMOOTH BACKING PLATES■ UPRIGHTS: 2" X 2" X 1/8" ANGLE IRON■ TRIM: STANDARD "WHITE" OR "BLACK" PIN STRIPING
■ SUSPENSION: 4-LEAVE EYE-TO-EYE SPRINGS SYSTEM■ TOP RAILS: 2" X 2" X 1/8" ANGLE IRON SQ-ENDS W/BOARD HOLDERS■ WARRANTY: A LIMITED TWO YEAR KEARNEY GUARANTEE
■ AXLES: ONE - 3.5K IDLER AXLE /CAMBERED W/ACCU-LUBE HUBS


STEP 1

Select A Trailer:

Model # App. Empty Wt. Description of Trailer Size Price
  BSSTDUT 4808 515 # 4' X 8' $CALL FOR QUOTE
  BSSTDUT 4810 605 # 4' X 10' $CALL FOR QUOTE
  BSSTDUT 6008 605 # 5' X 8' $CALL FOR QUOTE
  BSSTDUT 6010 670 # 5' X 10' $CALL FOR QUOTE
  BSSTDUT 6012 805 # 5' X 12' $CALL FOR QUOTE
  BSSTDUT 6014 940 # 5' X 14' $CALL FOR QUOTE
  BSSTDUT 7710 770 # 6'5" X 10' $CALL FOR QUOTE
  BSSTDUT 7712 925 # 6'5" X 12' $CALL FOR QUOTE
  BSSTDUT 7714 1080 # 6'5" X 14' $CALL FOR QUOTE
  BSSTDUT 8310 815 # 6'11" X 10' $CALL FOR QUOTE
  BSSTDUT 8312 980 # 6'11" X 12' $CALL FOR QUOTE
  BSSTDUT 8314 1140 # 6'11" X 14' $CALL FOR QUOTE

STEP 2

Select Additional Features:

Upgrade # Optional Upgrades Upgrade Price
  CP2RM 7K RAM A-FRAME COUPLER ILO 5K ATWOOD A-FRAME COUPLER $CALL FOR QUOTE
  JK2KFUJT 2K FOLD UP JACK ILO 2K TOP WIND JACK $CALL FOR QUOTE
  JK7KDL 7K DROP LEG SIDE WIND JACK ILO 2K TOP WIND JACK $CALL FOR QUOTE
  TR238PTR 2 3/8" PIPE TOP RAIL ILO 2"X2"X1/8" ANGLE TOP RAIL $CALL FOR QUOTE
  TNWT WRAP AROUND TOUNGE $CALL FOR QUOTE
  TG4 4' WIDE TAIL GATE $CALL FOR QUOTE
  TG5 5' WIDE TAIL GATE $CALL FOR QUOTE
  TG77 77" WIDE TAIL GATE $CALL FOR QUOTE
  TG83 83" WIDE TAIL GATE $CALL FOR QUOTE
  SMSTM SPARE TIRE MOUNT WELDED ON DRIVER OR PASSENGER SIDE $CALL FOR QUOTE
