Model #: BSSTDUT 3,500lb GVWR
■ COUPLER: 2" - 7K Ram W/Coupler Hole Cover Plate | ■ SAFETY CHAIN: 1/4" Chain W/Safety Hooks | ■ JACK: 2K Top Wind W/Interchangeable Pin On Sand Foot Jack Is Set Back For Tailgate Opening Clearance |
■ PLUG: 4 - Way Molded Plug Harness / Grounded To Frame | ■ LIGHTS: "LED" Rubber Mounted Running, Stop, Turn & Clearance | ■ FENDERS: 9" X 32" Rolled Smooth W/Smooth Backing Plates |
■ SUSPENSION: 4-Leaf Eye-To-Eye Springs System | ■ AXLES: One - 3.5K Dexter Idler / Cambered W/Accu-Lube Hubs | ■ TIRES: New ST-205-75-R-15" Radials Load Range "C" 6-Ply |
■ WHEELS: 5 - Hole Powder Coated Silver Mods / GM-5"-BP | ■ TONGUE: 5'X 12' & Smaller - 3" X 2" X 3/16" Angle Iron 5'X 1д' 8 All 77" & 93" Wides - 4" Channel Iron | ■ FRAME: 3" X 2" X 3/16" Angle Iron |
■ CROSS MEMBERS: 3" X 2" X 3/16" Angle Iron | ■ UPRIGHTS: 2" X 2" X 1/8" Angle Iron | ■ TOP RAIL: 2" X 2" X 1/8" Angle Iron Sq-Ends W/Board Holders |
■ FLOOR: #1 Pres Treated/2"X8" Pine Double Screwed/Per/Run | ■ TIE DOWNS: Four - Stake Pockets One On Each Corner | ■ STICKERS: Warning & Safety & Reflective Kearney Logos |
■ EXT. FINISH: Painted With A Newly Innovated Durable High Gloss Acrylic Polyurethane Full Two-Component Finish | ■ TOP UNDERCOATING: Completely Coated w/A Durable Protective Finish | ■ TRIM: Array of many colors to choose from |
■ WARRANTY: A Limited Two Year Kearney Guarantee |
