Model #: BTLTDUT 4,500lb GVWR
■ COUPLER: 2" - 7K Ram W/Coupler Hole Cover Plate | ■ SAFETY CHAIN: 1/4" Chain W/Safety Hooks | ■ JACK: 2K Top Wind W/Interchangeable Pin On Sand Foot Jack Is Set Back For Tailgate Opening Clearance |
■ PLUG: 4 - Way Molded Plug Harness / Grounded To Frame | ■ LIGHTS: "LED" Rubber Mounted Running, Stop, Turn & Clearance | ■ FENDERS: 9" X 72" 14Ga Straight Tread Plate W/Smooth Backing |
■ SUSPENSION: Equalizer W/4 Leave Eye To Eye Springs System | ■ AXLES: Two - 3.5K Dexter Idlers / Cambered W/Accu-Lube Hubs | ■ TIRES: New ST-205-75-R-15" Radials Load Range "C" 6-Ply |
■ WHEELS: 5 - Hole Powder Coated Silver Mods / GM-5"-BP | ■ TONGUE: 4" Channel Iron | ■ FRAME: 3" X 2" X 3/16" Angle Iron |
■ CROSS MEMBERS: 3" X 2" X 3/16" Angle Iron | ■ UPRIGHTS: 2" X 2" X 1/8" Angle Iron / 15" Tall | ■ TOP RAILS: 2"X2"X1/8" Angle Iron (Slope Back) |
■ FLOOR: #1 Pres Treated/2"X8" Pine Double Screwed/Per/Run | ■ MISC.: Two - Ramp Hanging Lips On Back (No Ramps) | ■ SPARE MOUNT: Spare Mount on Passanenger Side (No Spare) |
■ STICKERS: Warning & Safety & Reflective Kearney Logos | ■ EXT. FINISH: Painted With A Newly Innovated Durable High Gloss Acrylic Polyurethane Full Two-Component Finish | ■ UNDERCOATING: Completely Coated w/A Durable Protective Finish |
■ TRIM: Array of many colors to choose from | ■ WARRANTY: A Limited Two Year Kearney Guarantee |
