Model #: GTHDLBUT 14,000lb GVWR
| ■ COUPLER: 2-5/16" - GN Adj. W/Safety Pin & 2 - Set Screws | ■ SAFETY CHAIN: 3/8" Chain W/Safety Hooks | ■ JACK: Two - 12K Spring Loaded Drop Leg W/Sand Foot |
| ■ PLUG: 7 - Way Molded Plug Harness / Grounded To Frame | ■ LIGHTS: "LED" Rubber Mounted Running, Stop, Turn & Clearance | ■ FENDERS: 9" X 72" 14Ga Straight Tread Plate W/Smooth Backing |
| ■ SUSPENSION: Equalizer W/5 Leave Slipper Springs System | ■ AXLES: Two - 7K Dexter Axles / Cambered W/Accu-Lube Hubs | ■ BRAKES: One - Electric Brake W/Break Away & Charger |
| ■ TIRES: New ST-235-80-R-16" Radials Load Range "E" 10-Ply | ■ WHEELS: 8 - Hole Powder Coated Silver Mods | ■ SPARE MOUNT: Securely Mounted Inside Neck (Mount Only) |
| ■ TIE DOWNS: 10 - 3" Stake Pockets (5 - Ea. Side) | ■ STORAGE: Toolbox W/Lockable Lid Between GN Risers | ■ NECK: 12" X 14# I-Beam Neck & Risers |
| ■ RAMPS: 4' - 3" HD Channel Iron Slide In Ramps W/Holders 2 - Ramp Hanging Rod Lips On Back | ■ FRAME: 20' & Smaller - 5" X 3" X 1/4" Angle Iron 24' - 5" X 3" X 5/16" Angle Iron 26' & Larger - 6" X 4" X 3/8" Angle Iron | ■ CROSSMEMBERS: 4" X 3" X 1/4" Angle Iron On 24" Centers |
| ■ UPRIGHTS: 3" X 2" X 3/16" Angle Iron / 20" Tall | ■ TOP RAILS: 24' & Smaller 3" Pipe Sq-End W/Board Holders 26' & Larger 3" Sq-Tubing Sq-End W/Board Holders | ■ FLOOR: #1 Pres Treated/2"X8" Pine Double Screwed/Per/Run |
| ■ STICKERS: Warning & Safety/Dot & Reflective Kearney Logos | ■ EXT. FINISH: Painted With A Newly Innovated Durable High Gloss Acrylic Polyurethane Full Two-Component Finish | ■ UNDERCOATING: Completely Coated w/A Durable Protective Finish |
| ■ TRIM: Array of many colors to choose from | ■ WARRANTY: A Limited Two Year Kearney Guarantee |
