BUMPER TANDEM AXLE STANDARD DUTY LANDSCAPE 7,000lb GVWR

Model #: BTSTDLS 7,000lb GVWR

Standard Features

■ COUPLER: 2" - ATWOOD W/COUPLER HOLE COVER PLATE■ WHEELS: 5 - HOLE POWDER COATED SILVER MODS / GM-5"-BP■ TOP RAILS: 3" X 2" X 3/16" ANGLE IRON
■ SAFETY CHAIN: 1/4" CHAIN W/SAFETY HOOKS■ TAILGATE: 4' TALL EXPANDED MTL, W/SPRING LOADED LATCH PINS■ FLOOR: PRESSURE TREATED/2"X8"PINE,DOUBLE SCREWED/PER/RUN
■ JACK: 2K TOP WIND W/INTERCHANGEABLE PIN ON SAND FOOT *JACK IS SET BACK FOR TAILGATE OPENING CLEARANCE■ TIE DOWNS: FOUR 3" STAKE POCKET TIE DOWNS - ONE EACH CORNER■ STICKERS: WARNING & SAFETY & REFLECTIVE KEARNEY LOGOS
■ PLUG: 4 - WAY MOLDED PLUG HARNESS / GROUNDED TO FRAME■ STORAGE/RACK: 2'X 2'X WIDTH OF TRAILER LOCKABLE LANDSCAPE BOX *1 - SET OF LOCKABLE WEEDEATER RACKS (HOLDS - 3)■ EXT PREPPING: 2 STAGE DEGREASING AND ACID PHOSPHATE WASH W/RUST-INHIBITOR TO ENSURE MAXIMUM PAINT ADHESION
■ LIGHTS: "LED" RUBBER MOUNTED RUNNING, STOP, TURN & CLEARANCE■ TONGUE: 16'& SMALLER - 4" X 3" X 1/4" ANGLE IRON *18'& LARGER - 5" X 3" X 1/4" ANGLE IRON■ EXT. FINISH: PAINTED WITH A NEWLY INNOVATED, DURABLE HIGH GLOSS ACRYLIC POLYURETHANE FULL TWO-COMPONENT FINISH
■ FENDERS: 9" X 72" 14GA STRAIGHT TREAD PLATE W/SMOOTH BACKINGS■ SIDES: 48" TALL, EXPANDED METAL, W/SIDE BRACING■ UNDERCOATING: COMPLETELY COATED W/A DURABLE PROTECTIVE FINISH
■ SUSPENSION: EQUALIZER W/4-LEAVE EYE-TO-EYE SPRINGS SYSTEM■ FRAME: 16'& SMALLER - 3" X 2" X 3/16" ANGLE IRON *18'& LARGER - 5" X 3" X 1/4" ANGLE IRON■ TRIM: STANDARD "WHITE" OR "BLACK" PIN STRIPING
■ AXLES: TWO - 3.5K IDLER AXLES /CAMBERED W/ACCU-LUBE HUBS■ CROSSMEMBERS: 3" X 2" X 3/16" ANGLE IRON■ WARRANTY: A LIMITED TWO YEAR KEARNEY GUARANTEE
■ TIRES: NEW ST205/75/R/15" RADIALS LOAD RANGE "C" 6-PLY■ UPRIGHTS: 2" X 2" X 1/8" ANGLE IRON,BOTH BACK 3"X 2"X 3/16"


STEP 1

Select A Trailer:

Model # App. Empty Wt. Description of Trailer Size Price
  BTSTDLS 7712 1370 # 6'5" X 12' $
  BTSTDLS 7714 1600 # 6'5" X 14' $
  BTSTDLS 7716 1830 # 6'5" X 16' $
  BTSTDLS 7718 2060 # 6'5" X 18' $
  BTSTDLS 7720 2175 # 6'5" X 20' $
  BTSTDLS 8312 1410 # 6'11" X 12' $
  BTSTDLS 8314 1640 # 6'11" X 14' $
  BTSTDLS 8316 1880 # 6'11" X 16' $
  BTSTDLS 8318 2115 # 6'11" X 18' $
  BTSTDLS 8320 2350 # 6'11" X 20' $

STEP 2

Select Additional Features:

Upgrade # Optional Upgrades Upgrade Price
  CP2RM 7K 2" RAM A-FRAME COUPLER ILO 5K ATWOOD A-FRAME COUPLER $
  JK7KDL 7K DROP LEG SIDE WIND JACK ILO 2K TOP WIND JACK $
  TNWT43 4"X3"X1/4" WRAP AROUND TONGUE FOR 16' AND SMALLER $
  TNWT53 5"X3"X1/4" WRAP AROUND TONGUE FOR 18' AND 20' $
  TR238PTR 2 3/8" PIPE TOP RAIL ILO 3"X2"X3/16" ANGLE TOP RAIL $
  SB-WR EXTRA SET OF WEED EATER RACKS LOCKABLE HOLDS 3 $
  AX35BRK1 3.5K BRAKE ONE AXLE W/ BRAKE AWAY & 7 WAY RV PLUG $
  TD-DRWO 1/2" WELD ON D-RINGS-EACH $
  SMSTM SPARE MOUNT WELDED ON DRIVER OR PASSENGER SIDE $
